Home/ EV Chargers / Rayno Smart EV Charger EV04 | 7KW IP67 | RCM Certified

Rayno Smart EV Charger EV04 | 7KW IP67 | RCM Certified

SKU: EV04/AC07

Works with Your EV
Smart Charging for More EVs
Compatible with Top 5 Best-Selling Brands

BYD
Tesla
Kia
MG
Zeekr
$849.99
$1,049.99
$200.00

Product Highlights

Quantity

Back in stock alert

We'll notify you the moment this product becomes available again.

Oops, it looks like there was an error with your submission. Please try again later.

You're all set! We'll inform you once it's available again.


Secure Checkout

Payment methods

 Charge Smarter, Not Harder – Australia’s Most User-Friendly EV Charger

Most home EV chargers leave you guessing. Will it survive tomorrow's storm? Is it compatible with your new EV? Does your insurance even recognise it? The cheap options cut corners where it matters most.

 Why This Beats Other Home Chargers:

🛡️ Australian Certified Safety

The EV04 Rayno Smart EV Charger for Home carries IP67 and RCM certification. That means full dustproof protection and waterproofing to 1 metre for 30 minutes. Rain, heat, or dust — it handles Australian conditions without breaking a sweat. RCM certification meets local AS/NZS electrical standards, so your licensed electrician can sign off and your home insurance recognises it. Set it and forget it.

⚡ 7KW Fast Charging That Saves You Money

Standard wall socket charging gives you 10 amps and a 12-to-15-hour wait. The EV04 delivers 7KW at 32 amps. Same car, fully charged in 4 to 5 hours. Six current settings from 8A to 32A mean old house wiring? Set it to 13A. No rewiring needed. Then set the 1-to-10-hour timer for off-peak rates — typically 8pm to 7am across Australia. Your electricity bill can actually go down after buying an EV.

🔄 Four Ways to Charge

Most home chargers give you one option. The EV04 gives you four. Plug-and-charge — connect and it starts. No app, no card. IC card swipe — two cards included, perfect for family members who don't use apps. WiFi app control — schedule and monitor remotely via app.gocharge.tech. Auto-sense — phone near charger, car plugged in, charging starts automatically. WiFi drops? Use the card. Card lost? Plug and charge. There's always a way.

🖥️ LCD Screen and Ambient Light — Status at a Glance

A black box on the garage wall is what most EV chargers look like. The EV04 Rayno Smart EV Charger for Home features a 4.3-inch high-definition LCD screen. Walk in and check the current, time remaining, and charging mode without touching your phone. The dynamic ambient light ring tells you everything from across the garage: blue for standby, green solid for connected, green spinning for charging, red for fault.

🔌 One Charger for Every EV in Your Driveway

Type2 IEC 62196 is the Australian standard. The EV04 works with BYD Atto3, Dolphin, Tesla Model 3 and Y (with official adapter), Mercedes, Volvo, NIO, Xpeng, and 99% of Australian EVs. The 5-metre heavy-duty cable reaches any charging port — front, back, or side. Switch cars in three years? Your EV04 stays. No second installation. No second purchase.

🎁 The Gift That Charges Every Single Night

Twenty-four month warranty. Australian local support. CE and RCM certified. This isn't a set-it-and-hope-for-the-best purchase. The EV04 Rayno Smart EV Charger for Home is the home upgrade that keeps working — quietly, reliably, every night while you sleep. Know an EV owner still plugging into the wall? This is the gift. Housewarming, birthday, Christmas. The one they'll think about every morning when they wake up to a full battery.

Product Model: EV04 Rayno Smart EV Charger for Home

Input/Output Voltage: 240VAC 50/60Hz 1Phase (Australian standard)

Max Current: 32A

Max Power: 7KW

Input Frequency: 50Hz / 60Hz

Charging Interface: IEC 62196 Type2

Cable Length: 5m

Communication: WiFi + IC Card + LCD

Charging Modes: Plug-in / IC Card Swipe / WiFi App / Auto-Sense (4 modes)

Scheduled Charging: 1–10 hours (by phone or LCD)

Safety Protection: 12-layer (RCD AC30mA/DC6mA, over-voltage, under-voltage, over-current, short circuit, lightning, thermal, ESD)

IP Rating: IP67

Operating Temperature: -25°C to +50°C

Working Environment: Indoor / Outdoor

Certifications: CE + RCM

Display: 4.3" HD LCD Screen + Dynamic Ambient Light (Blue/Green/Red)

Product Dimensions: 385 × 284 × 80mm

Net Weight: 4–6kg

Warranty: 24 months

Colour: Carbon Grey

Material: Metal-look housing with anti-corrosion coating, gold-plated copper core Type2 connector, 5m heavy-duty cable

Installation: Wall-mounted. Requires licensed electrician. 240VAC circuit.

Compatible EVs: BYD Atto3/Dolphin/Seal, Tesla Model 3/Y (with adapter), Mercedes, Volvo, NIO, Xpeng, Audi e-tron, and 99%+ of Australian Type2 EVs

Yes. The EV04 uses the IEC 62196 Type2 interface — the Australian standard for AC EV charging. It is compatible with BYD Atto3, Dolphin, Tesla Model 3 and Y (official CCS2 adapter required for Tesla), Mercedes, Volvo, NIO, Xpeng, and 99% of EVs in Australia.

Yes, Australian electrical regulations require a licensed electrician for hardwired installations. The EV04 runs on 240VAC single phase, matching standard Australian home circuits. Most installations take 1 to 2 hours. Contact us for recommended local electricians.

Yes. The EV04 supports 1-to-10 hour scheduled charging, settable via the LCD screen or WiFi app. Australian off-peak rates are typically 8pm to 7am. Set it once and it charges automatically at the cheapest time each night.

Yes. The EV04 has four charging modes. If WiFi is unavailable, use the IC card swipe — two cards are included — or simply plug in and charge automatically. You are never dependent on a single method.

It depends on your home circuit. Most Australian homes can support 16A to 20A on existing circuits without upgrades. Use 8A to 10A for standard GPO circuits, 13A to 16A for a dedicated circuit, and 22A to 32A for a high-amp dedicated circuit for maximum speed. Your electrician will advise you during installation.
